Lattice Angle Towers for Power transmission
MEGATRO have a standard range of Lattice Towers to all our customers, which have three-legged, four-legged or every types to serve single circuit, double circuit, multi circuit, substation steelworks and other application. MEGATRO manufacture various types of Lattice Towers from slender single user options to large multi user switch structures. The types of construction fall into three broad categories; Angle Tower, Solid Rod Tower and Tubular Tower.
Lattice towers typically provide a more flexible solution compared to monopoles. Some of the benefits are the easy addition of additional antennas, flexibility in the feeder installation and good access to the telecoms equipment. Angle towers are one of the most economic solutions available. Manufactured automatically by our state of the art CNC machines, they are extremely quick to produce. Made from individual bolted elements, these structures are ideal for hand build sites and when supplied piece small, a complete tower occupies a low volume, which makes this type of tower ideal for shipping.
Towers can be supplied to account for future extendibility both in height and additional users. Other benefits include easy inspection and maintenance as corrosion of any elements will be clearly visible and can be easily treated.
After fabrication all towers are delivered to the galvanizing facility to be Hot DIP Galvanized. Towers are processed through the facility by Caustic Cleaning, Pickling, and then Fluxing. These strict procedures insure years of maintenance free towers.
Port of Loading: Qingdao Port
Lead Time: One month or based on the customer needs
Performance Standard: Besides conform to the drawing and design, the materials and fabrication of tower components shall conform to Chinese Standard or other international standard.
Payment: TT, LC
Delivery: 30 days against deposit or Negotiate
Origin: Shandong, China
Minimum Order: 10 tons
Packaging: Export standard package
Inspection: In house or their party inspection
Samples: Charge
Sample Price: US$1200
Lattice Towers
GSM, Microwave and Transmission Power Towers
Typical Production Towers - GSM, Microwave | ||||
Lattice Towers | Type | Tower | Antenna | |
Angular lattice with | 3 Legged | 18m - 70m | 12m² - 25m² | |
Angular lattice with | 4 Legged | 36m - 100m | 17m² - 56m² | |
| ||||
Angular lattice with | 4 Legged | 9m, 12m, 15m, 18m | 1,2m² | |
Typical Production Towers - Transmission Power |
Lattice Towers |
1. Double circuit, twin conductor suspension tower Etc. |
Angle Lattice Towers
Angle towers are one of the most economic solutions available. Manufactured automatically by our state of the art CNC machines here in Gloucester, they are extremely quick to produce. Made from individual bolted elements, these structures are ideal for hand build sites and when supplied piece small, a complete tower occupies a low volume, which makes this type of tower ideal for shipping.
Towers can be supplied to account for future extendibility both in height and additional users. Other benefits include easy inspection and maintenance as corrosion of any elements will be clearly visible and can be easily treated.
Solid Rod Lattice Towers
Solid bar towers combine slim, low impact solutions with good load carrying capabilities. The fully welded modules enable rapid installation of towers on site. For example, a tower up to 30 metres can be installed in a single day.
Tubular Lattice Towers
Tubular towers are ideal when you have a requirement to support large equipment loads at high levels. Made from structurally efficient tubes, the towers can be hand built and have a wide range of antenna mountings and work platforms are available. We can provide these towers at various heights up to 135 metres depending on the location and can be provided with up to 8 decks and the ability to house up to 70 dishes or 200 feeders.
